| Thickness(Inch) | Thickness(MM) | Application |
|---|---|---|
| 1/8'' | 3.175mm | Flexible And Thin, Mininal Friction ,High Precision ,Guiding Systems,Rail lining,and Light weight Machinery Components |
| 1/4'' | 6.35mm | Added Durability,No Selfied Flexibility,Mid-load Applications,Light-duty Conveyor Parts,Packaging Machinery,Protective Lining |
| 3/8'' | 9.525mm | Balance Between Thickness and Flexibility ,Agricultural Machinery Linings,Conveyor Chutes,And Sliding Surfaces Inlight Industrial Equipment |
| 1/2'' | 12.7mm | As Standard Industrial Thickness,Used In Heavy-duty Conveyor Systems,Cutting Surfaces,And Machinery Parts |
| 3/4'' | 19mm | Equipment Liners,Protective Guards,Structural Components |
| 1'' | 25.4mm | Loading-Bearing Surfaces,Heavy Equipment Liners,Impact-resistant Barriers,Maxmum Strength In Protection And Longevity |
| Grade | Description | Standard Colours |
|---|---|---|
| Virgin | Standard Uhmwpe | Natural/Black/Green/Colours |
| Anti-Static | Reduces Static Build-up,106_1011 ohms/sq Surface Resistivity | Black |
| Reprocessed | Eco-friendly And Eco Benefit | Black |
| Uv-Stabilized | Formulation For Outdoor Application | Black |
| Flame Retardant | Flame Retardant And Self-Extinguishing | Black |
| Borated Uhmwpe | Boron Loaded For Neutron Shielding Purposes | Black |
| Marine Grade | Low Friction,Excellent Impact Strength And Good Wear Resistance | Black/Yellow/Blue/Colours |
| Lining Grade | Ideal Material For The Bulk Material Handling And Mining Industry | Black/Blue/Grey/Natural |
| Tech | MoS2 Added For Improving Wear Resistance And Sliding Properties | Grey-Black |
| Oil Filled | Reduced Coefficient Of Friction | Grey |
| Glass Filled | Superior Wear Resistance And Dimensional Stability | Blue |
| Metal Detectable | Metal Detectable For Food Processing | Blue |
| Rubber Backed | Rubber Backing Allows The Use Of Adhesives | - |
| COLOR OPTION | APPLICATION |
|---|---|
| Green Uhmw | Agricultural ,Chute Liner,Clear Identification |
| Red Uhmw | Signaling And Alert Zones |
| Yellow Uhmw | Safety Applications,Zone For Clear Marking,Warehouse Markers,Equipment Guards |
| Blue Uhmw | Chemical Resistance,Ideal For Conveyor Belts,Cutting Surfaces,Food Packaging Equipment |
| White Uhmw | Food Grade,Sanitary Environment,Non-Toxic,Easy-to-Clean,Food Medical |
| Black Uhmw | Uv Resistance,Outdoor And Heavy Duty,Construction Liners,Mining Operation |
Finish:Planed/Smooth As Molded
Production Method:Compression Molded
Ultra High Molecular Weight Polyethylene UHMW-PE Products have a well-balanced property profile with a unique combination of wear and corrosion resistance,a low friction surface,and excellent impact strength.the property make UHMW-PE a universally usable material for a wide range of industries and applications
| Technical Data Sheet | |||
|---|---|---|---|
| Physical Properties | Test Standard | Value | Unit |
| Density | ASTM D792 | 0.93 | g/cm3 |
| Water Absorption | ASTM D570 | <0.10 | % |
| Mechanical Properties | Test Standard | Value | Unit |
| Hardness | ASTM D2240 | 62-66 | Shore D |
| Wear Resistance | Sand-Slurry | 100 | - |
| Tensile Strength at Yield 23℃ | ASTM D638 | 3100 | psi |
| Tensile Modulus | ASTM D638 | 100000 | psi |
| Elongation At Break | ASTM D638 | >350 | % |
| Flexural Strength | ASTM D790 | 3500 | psi |
| Compressive Strength | ASTM D695 | 3000 | psi |
| Coefficient Of Friction,Dynamic | - | 0.10-0.22 | - |
| Coefficient Of Friction,Static | - | 0.15-0.20 | - |
| Izod Impact,Notched | ASTM D256 | No Break | Ft-Lb/in |
| Izod Impact Strength | ASTM D4020 | 125 | KJ/M2 |
| Thermal Properties | Test Standard | Value | Unit |
| Service Temperature | - | -200 to 90 | ℃ |
| Melting Point | ASTM D3418 | 130 to 135 | ℃ |
| Vicat Softening Point | ISO 306 | 80 | ℃ |
| Heat Deflection Temperature | ASTM D648 | 43 | ℃ |
| Flammability,UL94 | - | HB | - |
| Electrical Properties | Test Standard | Value | Unit |
| Surface Resistivity | ASTM D257 | >1012 | Ω/cm |
| Volume Resistivity | ASTM D257 | >1015 | Ω/cm |
Size: As the most professional supplier in China, we have the most mold sizes for our customers to choose from. The maximum size is 2M*6M. And we can provide high-quality cutting services to meet the specific needs of different customers for sizes.
Thickness: According to different thickness requirements, We produces the UHMW liner with a thickness of 8mm (Min) and 200mm(Max).
Color: There is a wide range of standard colors available and colors can be customized according to RAL or Pantone color card.
Formulation: UHMW is a high-performance, versatile polymer that can be designed and formulated to meet your industrial needs.
